Note: Allow the carriage motor to cool before taking resistance measurements.
Table 34. Carriage Motor Resistance
Pins Resistance Temperature
1 and 2 0.44 ±0.02 Ohm
(±4.5%)
25°C (77°F)
3 and 4 0.44 ±0.02 Ohm
(±4.5%)
25°C (77°F)
Chapter 3. Circuit Diagrams
247
