Note: The following sample configurations are for illustration only and may not be suitable for any specific customer installation. Contact your IBM Business Partner or IBM
Marketing Representative for assistance with your specific configuration requirements.
High Availability Application Server
This rack server is configured to act as the foundation for business critical applications, applications your business cannot afford to be without. Configured with enough disk drives
to mirror the operating system and provide a standard RAID 5 environment for data, optional hot-swap redundant power and UPS for power even during a blackout, this server
represents the leading edge in high availability. An internal tape drive is included to back up that all important asset...data. A modem could be included to allow out-of-band (non-
LAN) system management utilising the integrated Netfinity Advanced System Management Processor.
Server Consolidation
This rack server is configured to meet the need of server consolidation. Many businesses are trying to get their arms around the dispersed departmental servers that have grown up
around the enterprise. By moving multiple servers on to one platform there is only one system to manage, both hardware and software. There is potentially less expense for service,
software licenses, etc., and there is less concern about single points of failure because the Netfinity 7600 is designed for high availability. This configuration includes 109 GB of
internal HDD storage, features three power supplies which provide fully redundant power, a UPS to help protect the system against a momentary electricity loss, and an internal tape
drive that backs up as much as 80GB per tape--in addition to all the standard features of the Netfinity 7600.
Netfinity 7600 Sample Configurations
Part Number Description Quantity Usage
53RYExx Netfinity 7600 700MHz/2MB Xeon, 512MB(R) ECC,RAID, Open, 40X, PCI 1 -
33L3113 Netfinity 128MB, 100MHz ECC SDRAM RDIMM 4 -
33L3115 Netfinity 256MB, 100MHz ECC SDRAM RDIMM 4 -
33L3117 Netfinity 512MB, 100MHz ECC SDRAM RDIMM 4 4 GB Total System Memory
10K2332 700 MHz/2MB Upgrade II with Pentium III Xeon Processor 3 Total of 4 SMP processors
37L7201 9.1GB Wide Ultra160 SCSI Hot-Swap SL HDD 2 9.1GB mirrored for NOS
37L7202 18.2GB Wide Ultra160 SCSI Hot-Swap SL HDD 6
1
72GB RAID 5 with Hot-Spare
00N7990 40/80GB DLT Internal SCSI Tape Drive 1 -
33L37xx 250W Hot-Swap Redundant Power Supply 1 Full Power Redundancy
T274Axx G78 Color Monitor 17” (454mm, 17.9” Viewable Image Size), stealth black 1 -
28L36xx Space Saver II Keyboard 1 -
14RIxxx APC Smart-UPS 1400RMB 1 -
External Storage
19K11xx EXP300 Storage Expansion Unit 1 Includes 2M Ultra2 cable
37L7206 Netfinity 36.4GB 10K-4 Wide Ultra160 SCSI Hot-Swap SL HDD 14
RAID 5 Data Storage with
Hot-Spare
Rack
9306200 Netfinity NetBAY22 1
09N4290 NetBAY 1x4 Console Switch 1
94G7448 Power Cable - Type C12 1
94G7447 NetBay Console Cable Set 12ft 1
94G6670 Blank Filler Panel Kit 1
1. Six HDDs are used for RAID 5 protection. One HDD is identified as a hot-spare. Effective storage capacity is four HDDs or 72.8GB
Part Number Description Quantity Usage
54RYExx Netfinity 7600 700MHz/1MB Xeon, 512MB(R) ECC, RAID, Open, 40X, PCI 1 -
33L3113 Netfinity 128MB, 100MHz ECC SDRAM RDIMM 4 1GB Total System Memory
10K2331 700 MHz/1MB Upgrade II with Pentium III Xeon Processor 1 Total of 2 SMP processors
37L7204 9.1GB 10K-4 Ultra160 SCSI Hot-Swap SL HDD 2 9.1GB mirrored for NOS
37L7205 18.2GB 10K-4 Ultra160 SCSI Hot-Swap SL HDD 8
1
109GB RAID 5 with Hot-Spare
34L1501 Netfinity 10/100 Ethernet PCI Adapter 2 3 Total of 4 Ethernet connections
00N7990 40/80GB DLT Internal SCSI Tape Drive 1 -
T274Axx G78 Color Monitor 17” (454mm, 17.9” Viewable Image Size), stealth black 1 -
28L36xx Space Saver II Keyboard 1 -
14RIxxx APC Smart-UPS 1400RMB 1 -
Rack
9306200 Netfinity NetBAY22 1 -
09N4290 NetBAY 1x4 Console Switch 1 -
94G7448 Power Cable - Type C12 1 Attaches to monitor
94G7447 NetBay Console Cable Set 12ft 1 -
94G6670 Blank Filler Panel Kit 2 -
1. Eight HDDs are used for RAID 5 protection. One HDD is identified as a hot-spare. Effective storage capacity is six HDDs or 109.2GB
