Notes:
v Do not install power supplies P00 and P01 AC jumper cables on the same AC input module.
v Service the FC 9094 bottom unit as an FC 9094 Base I/O Tower.
Possible failing
component
FRU name Position Type or CCIN
number (see the
Type, model, and
part number list)
Remove and
replace
procedure
Additional
comments
v High speed link
I/O adapter
v PCI host bridge
adapter
HSL I/O bridge
card
C10 2886 (See page
527), 2887 (See
page 527)
Go to FC
8094-001 (lower
half), FC 9094 -
Cards (dedicated)
Air moving device Air moving device B01, B02 See symbolic
FRU AIRMOVR
Go to FC 5094,
FC 9094 - Air
moving device -
B01 and B02
Power supply Power supply P00, P01, P02,
P03
See Final
assembly - FC
9094 Base I/O
Tower
Go to FC 5094,
FC 9094 - Power
supply - P00,
P01, P02, and
P03
AC power
distribution
assembly
AC module A01, A02 See Final
assembly - FC
9094 Base I/O
Tower
See either:
v Models 870
and 890 (FC
9094 with
single line
cord) - AC
module - A01
and A02
v Models 870
and 890 (FC
9094 with dual
line cord) - AC
module - A01
and A02
HSL cables HSL cables Attached to HSL
ports 0 and 1 on
HSL I/O bridge
card in C10
See the Plan for
cables topic in
Information
Center. This
information is also
available in the
Plan for hardware
and software
book.
Go to HSL cables
- concurrent
IOP PCI cards C01 through C03,
C05 through C08,
C11 through C14
2842 (See page
527), 2843 (See
page 527), or
2844 (See page
527)
Go to FC
8094-001 (lower
half), FC 9094 -
Cards
(concurrent)
IOA PCI cards C02 through C04,
C06 through C09,
C12 through C15
See the Type,
model, and part
number list
Go to FC
8094-001 (lower
half), FC 9094 -
Cards
(concurrent)
Analyze hardware problems 293
