Connectors and Functions of System Board of Machine Types 6266, 6270, 6276, 6279, 6280 and 6286

Table 5-1.Connectors and Functions of System Board of Machine Types 6266, 6270, 6276, 6279, 6280

and 6286

Connector Function

BATT Battery socket

FDD 1 Floppy connector

PCI Slot 1 PCI Slot 1

PCI Slot 2 PCI Slot 2

PCI Slot 3 PCI Slot 3

JBAT Clear CMOS jumper

JFP1 HDD LED, Power LED, Speaker, Power Switch and Reset Switch

IDE 1 Primary IDE

IDE 2 Secondary IDE

JWR1 ATX Power Connector

COMA Serial Port Connector 1

COMB Serial Port Connector 2

LPT1 Parallel Port Connector

VGA VGA Connector

JKBMS 1 Keyboard / Mouse connector

J5 CD-In Connector

J6 Aux Line In Connector

J7 Modem In Connector

USB Universal Serial Bus Connector
