Hard Disk Drive
To remove or replace the hard disk drive:
Disconnect the power and signal cables from the diskette drive.
Remove the two screws that secure the mounting tray at the bottom of the system unit.
Pull the drive mounting tray upward and remove it.
Remove the four screws (two on each side) that secure the hard diskette drive to the mounting tray.
Pull the hard disk drive from the mounting tray to remove.
Reverse the precedure to install a drive.
