Programming for Remote Monitor
The Remote Monitor feature allows one radio to open the mic of a targeted radio and hear any audio in the vicinity of
that radio. This feature is active for Individual radios, not for Talk Groups. Program your radio with the following
settings. All frequencies need to be entered and the squelch level must be set before performing this procedure.
Memory CH Window / Zone Operation Window
Field Setting/Description
Zone Operation » Zone Type
Set to Conventional (the field will show blank).
Memory CH Window / Zone Window
Field Setting/Description
CH Type Set to Digital
Digital » Unit ID
Set to this radio’s ID for the applicable channels. Points to
the ID setting in the Individual ID List window.
Digital » Squelch Type
Set to SEL if you want to squelch to open with the proper
RAN and Individual ID.
Remote Monitor Window
Field Setting/Description
RX Set to Enable to allow your radio to be monitored.
TX Set to Enable to be able to monitor a target radio.
TX Timer(Sec)
Set the time that you want your radio to be monitored by
another radio.
Common Window
Field Setting/Description
Key & Display » Key
Set one of the programmable keys to Digital Button.
To Monitor Another Radio
1. Press and hold the key assigned for Digital calls. The display will briefly show INDIVIDUAL or TALKGROUP.
If the selection is TALKGROUP, press and hold the key again, then press and hold to select INDIVIDUAL.
2. Press the up/down keys to select REM MON.
3. Press the Digital key quickly
to bring up the list of IDs.
4. Scroll to the desired radio ID by pressing the Up/Down keys.
5. Press PTT. If successful, your display will show REM TX, then REM ACK. If it failed, your display will show
REM FAIL. The green RX light on you radio will stay on as long as the mic is open on the target radio (the
duration set in the TX Timer(Sec) field).
