12
Appendix A: Temperature/Voltage Output Chart
This table applies when the I/O output of pin 10 is set to Temperature. The following temperatures and
voltages are based on a maximum output of 5V, and they vary as the internal temperatures of the repeater
changes.
Programmed
Temperature
(in celcius)
Voltage
Programmed
Temperature
(in celcius)
Voltage
-30 0.464106 37.5 3.924844
-27.5 0.539563 40 4.009059
-25 0.623751 42.5 4.086995
-22.5 0.716946 45 4.158974
-20 0.819274 47.5 4.225337
-17.5 0.930689 50 4.286434
-15 1.050951 52.5 4.342615
-12.5 1.179616 55 4.394226
-10 1.316033 57.5 4.441604
-7.5 1.459351 60 4.485072
-5 1.608537 62.5 4.524937
-2.5 1.76241 65 4.561488
0 1.919673 67.5 4.594997
2.5 2.078965 70 4.625718
5 2.238903 72.5 4.653885
7.5 2.398132 75 4.679716
10 2.555366 77.5 4.703412
12.5 2.70943 80 4.725157
15 2.859282 82.5 4.745119
17.5 3.004038 85 4.763453
20 3.142978 87.5 4.780301
22.5 3.275549 90 4.795792
25 3.40136 92.5 4.810043
27.5 3.520169 95 4.823162
30 3.631867 97.5 4.835246
32.5 3.736462 100 4.846384
35 3.83406
