Mixed Analog Repeating
A repeater set for mixed analog is capable of receiving both digital and analog signals, and will re-transmit in
the format received. The front hand mic will transmit in Analog.
Program your radio with the following settings. All frequencies need to be entered and the squelch level must
be set before programming the following settings.
Common Window
>
Set to Enable. When enabled, the Digital window appears.
Set to desired repeater Hang Time.
Memory CH Window
Multiple Table Window
Table No.
Set to desired number. Can have as many as 16 tables. If you
have created more than 1 table, entering a number in this field
will bring up the matching table.
Set to Analog or Digital.
Set to the desired CTCSS tone or RAN code set. Note: RAN
codes are decimal.
Enter RX and TX frequencies
Enter appropriate text for the channel name.
RF PWR Set the desired power level. Choices are L1 (5W), L2 (25W),
CH Type Set to Mixed-Ana. This allows receiving in analog and digital
and transmitting the same format as was received.
>
Set to ON (the CW window contains the timers and ID).
TX C Tone If the Multiple Table is not enabled, tones apply to TX only; RX
is open squelch. The front hand mic uses this TX tone.
If RX and TX tones are required, use the Multi Table to set the
tones.
Set to the desired number. It points to the tone/RAN settings in
the Multiple Table screen. The repeater will RX and TX for the
assigned channel using the tone/RAN sets referenced in this
window. Note: if there is no value entered, the radio will RX on
any tone and transmit on the tone entered in the TX C. Tone
field or, if set to Digital, will have no RAN for RX or TX.
No function in Mixed Analog Mode.
