4
Repeater Programming
Analog Repeating
A repeater set for analog receives and transmits on analog only. Program your radio with the following settings.
All frequencies need to be entered and the squelch level must be set before programming the following
settings.
Common Window
Others > Digital Function
Set to Enable, for future use of digital channels. Analog
operation is possible with this set to either Enable or Disable.
When enabled, the Digital window appears.
Set to desired Hang Time of the repeater
Memory CH Window
Multiple Table Window
Table No.
Set to desired number. Can have as many as 16 tables. If you
have created more than 1 table, entering a number in this field
will bring up the matching table.
Set to the desired CTCSS tone set. Repeater will operate on all
tone sets entered.
Enter the RX and TX frequencies.
Enter the appropriate text for the channel name.
Set the desired power level. Choices are L1 (5W), L2 (25W),
and High (50W).
>
Set to ON (the CW window contains the timers and ID).
Set the CTCSS/DTCS tone here. It is active in repeater mode
only If Multiple Table is not enabled, tones apply to TX only;
RX is open squelch. The front hand mic uses this TX tone.
If RX and TX tones are required, use the Multi Table to set the
Set to the desired table number. It points to the tone settings in
the Multiple Table screen. The repeater will RX and TX for the
assigned channel using all the tone sets referenced in this
window. Note: if there is no value entered, the radio will RX on
any tone and transmit on the tone entered in the TX C. Tone
