Icom IC-2300H Service Manual Addendum

1 - 1
SECTION 1
.
SPECIFICATIONS
M GENERAL
• Frequency coverage : (unit: MHz)
USA Tx: 144–148/Rx: 136–174*
Export Tx: 136–174*/Rx: 136–174*
Taiwan, Korea Tx/Rx: 144–146
*Guaranteed: 144–148 MHz range only.
• Type of emission : FM
• Number of memory channels : 207 (incl. 6 scan edges and 1 Call)
• Scan types : Full, Program, Priority, Memory
channel, Bank, Skip, Tone scans
• Frequency resolution : 5, 6.25, 10, 12.5, 15, 20, 25, 30,
50 kHz
• Operating temperature range : –10°C to +60°C; +14˚F to +140˚F
• Frequency stability : ±3 ppm
(–10°C to +60°C)
• Power supply requirement : 13.8 V DC ±15%
• Current drain (at 13.8 V DC: approximately):
Transmit at 65 W 11 A
( less than 9 A at 24 W for the Taiwan
version)
Receive standby 0.4 A
max. audio 1.5 A
• Antenna connector : SO-239 (50 Ω)
• Dimensions (proj. not included) : 140.0(W)×40.0(H)×118.0(D) mm;
5.5(W)×1.6(H)×4.6(D) in
• Weight (approximately) : 1.1 kg; 2.4 lb
M TRANSMITTER
• Modulation system : Variable reactance frequency mod.
• Output power (approximately) :
• Max. frequency deviation : ±5.0 kHz (Wide)/±2.5 kHz (Narrow)
• Spurious emissions : Less than –60 dBc
• Microphone connector : 8-pin modular (600 Ω)
M RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 46.35 MHz, 2nd: 450 kHz
• Sensitivity (at 12 dB SINAD) : Less than 0.18 µV
• Squelch sensitivity : Less than 0.13 µV (threshold)
• Selectivity :
[Wide] More than ±6 kHz/6 dB
Less than ±14 kHz/60 dB
[Narrow] More than ±3 kHz/6 dB
Less than ±9 kHz/55 dB
• Spurious and image rejection : More than 60 dB
• AF output power (at 13.8 V DC) : More than 3.5 W (4.5 W typical)
(at 10% distortion with a 4 Ω load)
• External speaker connector : 3-conductor 3.5 (d) mm (
1
/8 inch)/4 Ω
All stated specifi cations are subject to change
without notice or obligation.
USA, Export Taiwan Korea
High:
65 W 24 W 50 W
Mid:
25 W 10 W 25 W
Mid-Low:
10 W – 10 W
Low:
5 W 5 W 5 W

Icom IC-2300H Specifications

General

Radio type	Portable
Supported radio bands	FM
RMS rated power	65 W
Display type	LCD
Backlight color	Amber/Yellow/Green
Built-in display	Yes
Headphone connectivity	3.5 mm
Product color	Black
Power source	DC
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	162 mm
Width	140 mm
Height	40 mm
Weight	1100 g
