4-5
4-4 TRANSMIT ADJUSTMENTS
• Touch [TX/ID] on the main menu screen.
ADJUSTMENT ADJUSTMENT ITEM DISPLAY SETTING CONDITION OPER ATION
PREPARATION 1 – • Connect the RF power meter to the
[ANT1] connector.
Touch [ID] to start the
transmitter adjustment.
ID
ADJUSTMENTS
2 VDL IDL SET • Receiving Touch [SET].
(Two beeps sound 0.5
seconds later.)
3 FINAL ID SET
4 FINAL1 IDV • Automatically transmitted.
5 FINAL2 IDV
6 DRIVER ID SET • Receiving
7 DRIVER1 IDV • Automatically transmitted.
8 DRIVER2 IDV
9 PRE DRIVER ID SET • Receiving.
10 PRE DRIVER1 IDV • Automatically transmitted.
TX POWER
ADJUSTMENT
PREPARATION
11 TX POWER SET • Connect the audio generator to the
[MIC] connector and set it to:
Frequency: 1.5 kHz
Level: 10 mV rms
• Receiving.
Touch [SET].
SWR DETECT
NULL POINT
12 SWR detector adjustment • Automatically transmitted. Touch [SET].
(Two beeps sound 0.5
seconds later.)
TRANSMIT
OUTPUT
POWER (HF)
13 TX Total HF Gain • Automatically transmitted. Set to 50 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
14 POWER HF 1% Set to 1 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
15 POWER HF 10% Set to 10 W by [DIAL], then
touch [SET].
16 POWER HF TUNE (Two beeps sound 0.5
seconds later.)
17 POWER HF 50% Set to 50 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
18 POWER HF 100% Set to 103 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
AM CARRIER
POWER R ATE
19 POWER AM Ratio HF • Receiving. Touch [SET].
20 • Automatically transmitted. Set to 25 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
TRANSMIT
OUTPUT
POWER
(50 MHz band)
21 POWER 50M SET • Receiving. Touch [SET].
22 TX Total 50M Gain • Automatically transmitted. Set to 50 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
23 POWER 50M 1% Set to 1 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
24 POWER 50M 10% Set to 10 W by [DIAL], then
touch [SET].
25 POWER 50M TUNE (Two beeps sound 0.5
seconds later.)
26 POWER 50M 50% Set to 50 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
27 POWER 50M 100% Set to 103 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
