4-6
ADJUSTMENT ADJUSTMENT ITEM DISPLAY SETTING CONDITION OPER ATION
AM CARRIER
POWER R ATE
28 POWER AM Ratio 50M • Receiving. Touch [SET].
29 • Automatically transmitted. Set to 25 W by [DIAL], then
touch [SET].
(Two beeps sound 0.5
seconds later.)
ALC
ADJUSTMENT
30 ALC HF • Receiving. Touch [SET].
31 • Automatically transmitted. Two beeps sound 3 seconds
later.
32 ALC 50M • Receiving. Touch [SET].
33 • Automatically transmitted. Two beeps sound 3 seconds
later.
DRIVE GAIN
ADJUSTMENT
34 DRIVE HF • Receiving. Touch [SET].
35 • Automatically transmitted. Two beeps sound 10 seconds
later.
36 DRIVE 50M • Receiving. Touch [SET].
37 • Automatically transmitted. Two beeps sound 3 seconds
later.
SWR METER
ADJUSTMENT
38 SWR2(HF) • Connect the 100 Ω dummy load to
[ANT2].
• Receiving.
Touch [SET].
39 • Automatically transmitted. Two beeps sound 3 seconds
later.
40 SWR2(50M) • Receiving. Touch [SET].
41 • Automatically transmitted. Two beeps sounds 3 seconds
later.
Id APC
ADJUSTMENT
42 ID-APC • Receiving Touch [SET].
43 • Automatically transmitted. Two beeps sound 2 seconds
later.
• After the adjustment, the transceiver shows the TX/ID adjustment menu.
• Push [EXIT] to return to the menu screen.
4-5 ANTENNA TUNER/REFERENCE ADJUSTMENTS
• Touch [TUNER/REF] on the main menu screen.
ADJUSTMENT ADJUSTMENT ITEM DISPLAY SETTING CONDITION OPER ATION
PREPARATION 1 – • Connect the RF power meter to
[ANT1].
Touch [TUNER] to start
the tuner reference voltage
adjustment.
TUNER
REFERENCE
VOLTAGE
ADJUSTMENT
2 Tune IREFV HF 50M • Receiving. Touch [SET].
3 • Automatically transmitted. Two beeps sound 11 seconds
later.
REFERENCE
FREQUENCY
ADJUSTMENT
4 REF OSC • Connect the frequency counter
to [ANT1] through a suitable
attenuator.
• Receiving
Touch [SET].
5 • Automatically transmitted. Set the frequency to
50.100 MHz ±1.2 Hz by [DIAL],
then touch [SET].
(Two beeps sound 0.5
seconds later.)
REFULK
ADJUSTMENT
6 ULKck • Receiving. Touch [SET].
(Two beeps sound 0.5
seconds later.)
• After the adjustment, the transceiver shows the TUNER/REF adjustment menu.
• Push [EXIT] to return to the menu screen.
4-4 TRANSMIT ADJUSTMENTS (continued)
