SECTION 6 MECHANICAL PARTS
REF PART
DESCRIPTION QTY.
NO. NO.
REF PART
DESCRIPTION QTY.
NO. NO.
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to
“
GENERAL WIRING
”
for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head NI: Nickel ZU: Zinc SUS: Stainless
6-1
[CHASSIS UNIT] [MAIN UNIT]
J1 6510028411 MR-DS-01-2 1
J2 6510028411 MR-DS-01-2 1
SP1 2510002111 3864 SP BOX-1 1
MF1 2710001060 FD128025HB-N (2N7R1) 1
W1 8920002130 CAB-1257 1
W2 8920002130 CAB-1257 1
W3 8920002130 CAB-1257 1
W4 8920002130 CAB-1257 1
W11** 8600037610 SX3864 P11*P12CH (3864-1) 1
W21** 8600037620 SX3864 P21*22/P31*32CH (3864-2) 1
W31** 8600037620 SX3864 P21*22/P31*32CH (3864-2) 1
W41** 8600037630 SX3864 P41*P42*P43CH (3864-3) 1
W51** 8920002350 CAB-1304 (3864-6) 1
W61** 8920002360 CAB-1305 (3864-7) 1
W71** 8600037660 SX3864 J71*P72CH (3864-8) 1
W101** 8970025740 1.5DCOAXIAL210MM (A)-2 C31/C31 1
W111** 8970025740 1.5DCOAXIAL210MM (A)-2 C31/C31 1
W121** 8970025750 1.5DCOAXIAL240MM (A)-2 C31/C31 1
W131** 8970025750 1.5DCOAXIAL240MM (A)-2 C31/C31 1
W141** 8970025750 1.5DCOAXIAL240MM (A)-2 C31/C31 1
W151** 8970025750 1.5DCOAXIAL240MM (A)-2 C31/C31 1
W161** 8970025760 1.5DCOAXIAL270MM (A)-2 (G)C31/C31 1
W171** 8970025760 1.5DCOAXIAL270MM (A)-2 (G)C31/C31 1
W181** 8970025780 1.5DCOAXIAL330MM (A)-2 (T)C31/C31 1
W191** 8970024312 1.5DCOAXIAL420MM-2 (A) C31/C31 1
W201** 8970024851 1.5DCOAXIAL750MM-1 (P) C31/C31 1
W211** 8970025770 1.5DCOAXIAL300MM (A)-2 C31/C31 1
W301** 8910000350 FFC-1033 (P0.5N30L270) 1
W302** 8910000500 FFC-1055 (P0.5N30L150) 1
W303** 8910000141 FFC-1015-1 (P0.5N30L80) 1
W304** 8910000141 FFC-1015-1 (P0.5N30L80) 1
W305** 8900018000 OPC-1344A (P1N10L70) 1
W306** 8900018000 OPC-1344A (P1N10L70) 1
W307** 8900016110 OPC-1680 (P0.5N30L100) 1
W308** 8900013541 OPC-1410A (P0.5N14L50) 1
EP1 6910025930 S80-5 1
EP161** 6910011960 ZCAT1518-0730 1
MP1 8010023931 3864 CHASSIS-1 M200 1
MP2 8110011150 3864 U-COVER 1
MP3 8110011160 3864 L-COVER 1
MP4 8510022030 3864 SHIELD COVER 1
MP5 8510022040 3864 RF-SHIELD COVER 1
MP6 8930077030 3073 MAIN STAND 2
MP7 8930077040 3073 SUB STAND 2
MP8 8930040590 RUBBER LEG (K)/FF-008 (P4060)-AR791 2
MP9 8930046120 RUBBER REG (M) /FF-013 (P3555)-AR791 4
MP10 8930077020 3073 A-STAND SHEET 2
MP11 8930077490 3073 B-STAND SHEET 2
MP12 8930077650 3073 SIDE HANDLE (5) 1
MP13 8810008160 HEXBOLT M5×18 NI (+) 1
MP14 8830000211 NUT M5 BS-CD NI 1
MP15 8830000360 NUT M5 NI 1
MP16 8850000150 FLAT WASHER M5 NI BS 3
MP17 8850000440 S-WASHER M5 NI 1
MP18 8930095560 3818 RUBBER (TOP) 4
MP19 8930095570 3818 SPACER 4
MP20 8930035230 1546 TR-A CLIP 2
MP21 8930090940 PA-30B 3
MP22 8930043800 DOUBLE SIDE TAPE (S) 2
MP23 8930097080 3864 NET 1
MP24 8930096750 HIMELON SHEET (DZ) 1
MP25 8930094660 SPONGE (OC) 1
MP26 8950003640 CS-2 1
MP27 8950003640 CS-2 1
MP29 8930043800 DOUBLE SIDE TAPE (S) 1
MP30 8930076950 THERMAL SHEET (BP)TC800HS-1.4 (15X22) 1
MP31 8950003640 CS-2 1
MP101 8810008661 PHBT M3×8 NI-ZC3 16
MP102 8810008661 PHBT M3×8 NI-ZC3 15
MP103 8810008661 PHBT M3×8 NI-ZC3 12
MP104 8810008661 PHBT M3×8 NI-ZC3 7
MP105 8810008661 PHBT M3×8 NI-ZC3 12
MP106 8810008661 PHBT M3×8 NI-ZC3 7
MP107 8810008661 PHBT M3×8 NI-ZC3 4
MP108 8810008661 PHBT M3×8 NI-ZC3 2
MP109 8810007231 SET SCREWH M3×8 ZC3 11
MP110 8810007231 SET SCREWH M3×8 ZC3 8
MP111 8810007231 SET SCREWH M3×8 ZC3 7
MP112 8810009311 FLAT BT M3×6 NI-ZC3 4
MP113 8810011180 SET SCREW (H) 3×20 ZK3 4
MP114 8810010580 SET SCREWA M4×32 4
MP115 8810005771 BIND M3×8 ZK3BLACK 16
MP116 8810010870 ROUND FLAT M4×12 ZK3 2
MP201 8930069580 THERMAL SHEET (BA) TC-600HS-1.4 1
MP202 8930098230 EMBOSS TAPE (Q) 3
MP204 8930091700 HIMELON SHEET (DL) 2
MP205 8930098400 FERRITE SHEET (BK) 3
J101* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J151* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J201* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J251* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J301* 6510022022 14FLT-SM2-TB (LF) (SN) (M) 1
J321* 6510021261 B9B-ZR-SM4-TF (LF) (SN) 1
J331* 6510021441 B6B-ZR-SM4-TF (LF) (SN) 1
J341* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1
J351* 6510022891 B13B-ZR-SM4-TF (LF) (SN) 1
J361* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J451* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J601* 6510019971 52808-1071 1
J602* 6510019371 B3B-ZR-SM4-TF (LF) (SN) 1
J611* 6510019971 52808-1071 1
J612* 6510019371 B3B-ZR-SM4-TF (LF) (SN) 1
J2001* 6510022311 B5B-PH-SM4-TB (LF) (SN) 1
J3051* 6510025940 PJ-3047S 1
J3061* 6510025940 PJ-3047S 1
J3071* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1
J4501* 6510028210 SJ050010 (TMP-J01X-V6) 1
J5391* 6510027290 52808-0671 1
J6201* 6450002570 74320-4004 1
J7121* 6510026540 UBB-4R-D14T-4D (LF) (SN) 1
J7401* 6510024040 TM11R-5M2-88-LP 1
J8001* 6510028210 SJ050010 (TMP-J01X-V6) 1
J8501* 6510028210 SJ050010 (TMP-J01X-V6) 1
J8502* 6510028210 SJ050010 (TMP-J01X-V6) 1
J8521* 6510028210 SJ050010 (TMP-J01X-V6) 1
J9401* 6510031890 ABA-USB-068-P06_A 1
J9701* 6510026490 60RF-JMCS-G-1B-TF (N) (LF) (SN) 1
F1351* 5210001250 ERBRE1R25V 1
T7401* 5920000990 H1102FNLT 1
BT4221* 3020000390 ML414HIV01E 1
EP8200* 6910026020 CMBA0210101402-00 1
EP8700* 6910026020 CMBA0210101402-00 1
EP8901* 6910026920 CMBA0140402001-00 1
MP1001* 8510020100 3182 DC-DC CASE 1
MP1002 6910008240 59TN4772 (SPCC) 1
MP1003 8930065721 SHIELD SPONGE (AP)-1 1
MP1004 8930071711 SHIELD SPONGE (BO)-1 1
MP1351* 8510020100 3182 DC-DC CASE Y1220 1
MP2401* 8510019110 3073 PLL CASE 1
MP2601 8930096760 3864 DVI PLATE 1
MP2602 8930093330 71781-1000 2
MP4001* 8930071160 2427 F-EARTH SPRING 1
MP5001* 8930071160 2427 F-EARTH SPRING 1
MP8101* 8510021830 3765 S-CASE Y1382 1
MP8102* 8930071160 2427 F-EARTH SPRING 1
MP8601* 8510021830 3765 S-CASE Y1382 1
MP9051* 8510021830 3765 S-CASE Y1382 1
MP9101* 8510013830 2356 B-SHIELD PLATE 1
MP9801* 8930071160 2427 F-EARTH SPRING 1
