Icom IC-7610 User Manual

1-2
Receiver
● Receive system Direct sampling superheterodyne system
● Intermediate frequency 12 kHz
● Receive sensitivity
(For USA and EXP/Filter shape=Soft)
SSB/CW 1.8 MHz~29.999 MHz –16 dBμ (0.16 μV) typ. (10 dB S/N) (Preamp1 ON)
50 MHz band –18 dBμ (0.13 μV) typ. (10 dB S/N) (Preamp2 ON)
AM 0.5 MHz~1.799 MHz +16 dBμ (6.3 μV) typ. (10 dB S/N) (Preamp1 ON)
1.8 MHz~29.999 MHz +6 dBμ (2.0 μV) typ. (10 dB S/N) (Preamp1 ON)
50 MHz band 0 dBμ (1.0 μV) typ. (10 dB S/N) (Preamp2 ON)
FM 28.0 MHz~29.7 MHz –6 dBμ (0.5 μV) typ. (12 dB SINAD) (Preamp1 ON)
50 MHz band –10 dBμ (0.32 μV) typ. (12 dB SINAD) (Preamp2 ON)
● Receive sensitivity
(For EUR/Filter shape=Soft)
SSB/CW (BW=2.4 kHz)
1.8 MHz~2.999 MHz Less than +10 dBµV emf (12 dB SINAD) (Preamp1 ON)
3.0 MHz~29.999 MHz Less than 0 dBµV emf (12 dB SINAD) (Preamp1 ON)
50 MHz band Less than –6 dBµV emf (Preamp2 ON)
AM (BW=4 kHz/60% Mod.)
1.8 MHz~2.999 MHz Less than +16 dBµV emf (12 dB SINAD) (Preamp1 ON)
3.0 MHz~29.999 MHz Less than +6 dBµV emf (12 dB SINAD) (Preamp1 ON)
50 MHz band Less than 0 dBµV emf (12 dB SINAD) (Preamp2 ON)
FM (BW=7 kHz/60% Mod.)
28 MHz~29.7 MHz Less than 0 dBµV emf (12 dB SINAD) (Preamp1 ON)
50 MHz band Less than –6 dBµV emf (12 dB SINAD) (Preamp2 ON)
● Squelch sensitivity
SSB Less than +10 dBμ (3.2 μV)
FM Less than –10 dBμ (0.32 μV)
● Selectivity (Filter shape=SHARP)
SSB (BW=2.4 kHz) More than 2.4 kHz/–6 dB, Less than 3.6 kHz/–60 dB
CW (BW=500 Hz) More than 500 Hz/–6 dB, Less than 700 Hz/–60 dB
RTTY (BW=500 Hz) More than 500 Hz/–6 dB, Less than 700 Hz/–60 dB
AM (BW=6 kHz) More than 6.0 kHz/–6 dB, Less than 15 kHz/–60 dB
FM (BW=15 kHz) More than 12.0 kHz/–6 dB, Less than 20 kHz/–60 dB
● Spurious and image rejection ratio
HF bands 70 dB
50 MHz band 70 dB (Except for ADC aliasing)
● Audio output power More than 2 W (at 10% distortion into an 8 Ω load)
● Audio output impedance 8 Ω
● RIT variable range ±9.999 kHz
Antenna tuner
● Matching impedance range 16.7 Ω~150 Ω (unbalanced) (VSWR 3:1 or less)
● Tuning time 2~3 seconds (average/15 seconds maximum)
● Tuning accuracy VSWR 1.5:1 or less
