SOFTWARE ADJUSTMENT – continued
Select an item using [CH-UP] / [CH-DN] buttons, then set specified value using [RPT/BASE] / [MONI] buttons on the FRONT
PANEL.
1
2
1
• LCD display :
A10 LW CTCDEV
• Operating freq. : 415.2750 MHz 1, 4
440.2750 MHz 2
465.2750 MHz 3, 5
• Set the FM deviation meter as:
HPF : OFF
LPF : 20 kHz
De-emphasis: OFF
Detector : (P–P)/2
• No audio applied to the [MIC] connector.
• Transmitting
• LCD display :
A12 LN CTCDEV
• Operating freq : 415.2750 MHz 1, 4
440.2750 MHz 2
465.2750 MHz 3, 5
• No audio applied to the [MIC] connector.
• Transmitting
• LCD display :
A11 LW DTCADJ
• Operating freq. : 415.2750 MHz 1, 4
440.2750 MHz 2
465.2750 MHz 35
• No audio applied to the [MIC] connector.
• Transmitting.
Rear
panel
Rear
panel
Connect the FM deviation meter
to the [TX] antenna connector
through the attenuator.
Connect the FM deviation meter
with the oscilloscope to the [TX]
antenna connector through an
attenuator.
±0.7 kHz
1, 2, 3
±0.56 kHz 4, 5
±0.35 kHz
ADJUSTMENT ADJUSTMENT CONDITION
MEASUREMENT
VALUE
UNIT LOCATION
*The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.
1: [USA1], [GEN1], [GEN5], [EUR1] 4: [FRG1]
2: [GEN2], [GEN6] 5: [FRG3]
3: [USA3], [GEN3], [GEN7], [EUR3]
To Next Page
