SOFTWARE ADJUSTMENT continued
Select an item using [CH-UP] / [CH-DN] buttons, then set specified value using [RPT/BASE] / [MONI] buttons on the FRONT
PANEL.
1
2
LCD display :
A13 LW RPTAF
Operating freq : 410.2750 MHz
(RX)
1, 4
415.2750 MHz
(TX)
1, 4
440.0750 MHz
(RX)
2
440.2750 MHz (TX) 2
460.2750 MHz
(RX)
3, 5
465.2750 MHz
(TX)
3, 5
Connect the standard signal generator
to the [RX] antenna connector and set
as:
Level : 1 mV* (47 dBm)
Modulation : 1 kHz
Deviation : ±3 kHz 1, 2
±2.4 kHz 3
Transmitting
LCD display :
A14 LN RPTAF
Operating freq : 410.2750 MHz
(RX)
1, 4
415.2750 MHz
(TX)
1, 4
440.0750 MHz
(RX)
2
440.2750 MHz (TX) 2
460.2750 MHz
(RX)
3, 5
465.2750 MHz
(TX)
3, 5
Connect the standard signal generator
to the [RX] antenna connector and set
as:
Level : 1 mV* (47 dBm)
Modulation : 1 kHz
Deviation : ±1.5 kHz
Transmitting
REPEATER
DEVIATION
[WIDE]
[NARROW]
Rear
panel
Connect the FM deviation meter
to the [TX] antenna connector
through the attenuator.
±3.0 kHz 1, 2, 3
±2.4 kHz 4, 5
±1.5 kHz
ADJUSTMENT ADJUSTMENT CONDITION
MEASUREMENT
VALUE
UNIT LOCATION
*The output level of the standard signal generator (SSG) is indicated as the SSGs open circuit.
1: [USA1], [GEN1], [GEN5], [EUR1] 4: [FRG1]
2: [GEN2], [GEN6] 5: [FRG3]
3: [USA3], [GEN3], [GEN7], [EUR3]
