■ Recommendation
CLEAN THE TRANSCEIVER AND MICROPHONE THOROUGHLY WITH FRESH
WATER after exposure to saltwater, and dry it before operating. Otherwise, the
transceiver’s keys and switches may become unusable, due to salt crystallization.
NOTE: If the transceiver’s waterproof protection appears defective, carefully clean it
with a soft, damp (fresh water) cloth, then, dry it before operating.
The transceiver may lose its waterproof protection if the case or microphone is cracked
or broken, the microphone connector is not screwed in completely, or the transceiver
has been dropped.
Contact your Icom distributor or your dealer for advice.
■ Key Icon Description
The keys are described in this manual as follows:
The keys that have words or letters on them are described with the characters “[ ].”
Example: [MENU], [CLEAR]
The software keys are described with the icon such as
or
. The function of the
keys are shown at the bottom of the display. Push the key below the desired function.
You can use the following keys on the Menu screen.
FUNCTION ACTION
Select
Push [▼] or [▲], or rotate [CH/ENT].
Enter
Push [ENT], or [CH/ENT].
Go to the next tree level
Push [ENT], [►], or [CH/ENT].
Go back to the previous tree level
Push [CLEAR], or [◄].
Cancel
Push [CLEAR] or
.
Exit
Push [MENU] or
.
Information:
In this instruction manual, the transceiver model names are described as shown below.
U.S.A.: USA
Europe: EUR, General
Germany: FRG
Netherlands: NLD
U.K.: UK
