SPECIFICATIONS
3
13
• Frequency coverage (MHz)
U.S.A. : 0.010000–823.999999*
849.000001–868.999999
894.000001–1300.000000
Europe : 0.010000–1300.000000*
* Specifications guaranteed 0.5–1300 MHz only.
• Receive system : Triple superheterodyne
• Mode : WFM, FM, AM, SSB, CW
• Frequency stability : ±3 ppm at 1300 MHz
(0°C to +50°C; 32°F to +122°F)
• Frequency resolution : 1 Hz (minimum)
• Power supply requirement :13.8 V DC ±15 % for receiver unit;
or, supplied AC adapter
(negative ground)
• Current drain (at 13.8 V DC)
Power ON (PC power OFF) : 0.1 A
Max. audio : 0.7 A
Standby (squelched) : 0.6 A
• Usable temp. range : 0°C to +50°C; +32°F to +122°F
• Intermediate frequencies
1st : 266.7 MHz
2nd : 10.7 MHz
3rd : 450 kHz (except WFM)
• Receive sensitivity (typical)*:
*When 230 kHz (for WFM), 15 kHz (for FM), 6 kHz (for AM) and 2.8
kHz (for SSB/CW) passband widths are selected.
• Squelch sensitivity (threshold):
Frequency
(MHz)
SSB/CW
(10 dB S/N)
AM
(10 dB S/N)
FM
(12 dB SINAD)
WFM
(12 dB SINAD)
0.5–1.799999 0.56 µV 2.5 µV
—
—
1.8–27.99999
0.28 µV 1.4 µV
30–49.99999 0.35 µV 1.8 µV
50–699.99999 0.2 µV 1.0 µV 0.32 µV 0.79 µV
700–1300 0.25 µV 1.3 µV 0.4 µV 1.0 µV
28–29.99999
0.5 µV
Frequency
(MHz)
SSB/CW AM FM WFM
0.5–1.799999 14 µV 1.8 µV
—
—
1.8–27.99999
7.1 µV 0.89 µV
30–49.99999
50–699.99999 5.6 µV 0.71 µV 0.5 µV 5.6 µV
700–1300 7.1 µV 0.89 µV 0.63 µV 7.1 µV
28–29.99999
0.63 µV
