3
SPECIFICATIONS
14
• Selectivity
WFM : 230 kHz/–6 dB
WFM/FM/AM : 50 kHz/–6 dB
FM/AM : 15 kHz/–6 dB
FM/AM/SSB/CW : 6 kHz/–6 dB
AM/SSB/CW : 2.8* kHz/–6 dB
*Software indicates 3 kHz.
• IF shift range : More than ±1.2 kHz
• Max. audio output : 200 mW
(at 10% distortion with an 8 Ω load)
• Antenna connector : BNC (50 Ω)
• RS-232C connector : D-sub 9-pin (female)
• Ext. speaker connector : 3-conductor 3.5 (d) mm (
1
⁄8")/
4–8 Ω
• Dimensions : 127.5(W) × 30(H) × 199(D) mm
(projections not included) 5(W) × 1
3
⁄16(H) × 7
27
⁄32(D) in
• Weight : approx. 1 kg; 2 lb 3 oz.
All stated specifications are subject to change without
notice or obligation.
