Icom IC-R6 Service Manual

5 - 2
ADJUSTMENT
RECEIVER’S
CONDITION
OPERATION
ADJUSTMENT
ITEM
VALUE
REFERENCE
FREQUENCY
1 • Frequency: 439.800 MHz • Connect a frequency counter to "2nd
LO" line on the RF UNIT as illustrated
below.
247.050 MHz
(±120 Hz)
5-2 FREQUENCY ADJUSTMENT
1) Select an adjustment item using [BAND]/[TS].
2) Set or modify the adjustment value as specifi ed using [DIAL], then push [V/M] to store the adjustment value..
RF UNIT
¤ LOCATION
The 2nd LO line
