Icom IC-V80E User Manual

Stores adjustment value
Starts automatic adjustment
Selects next adjustment item
(without storing value)
Selects previous adjustment item
Adjusts the value for the item
TX power
Adjustment frequency
Adjustment item
[VFO/MR/CALL]
[ ]
[ ]
JIG cable “#1”
(See the page 5-1)
To [SP]
5 - 2
M ENTERING ADJUSTMENT MODE
1) Turn the power OFF.
2) Connect
the JIG cable "#1" (See the page 5-1) to the [SP] jack.
3) While pushing
[
Y
], [
Z
]
and [VFO/MR/CALL], turn the power ON.
M
QUITTING ADJUSTMENT MODE
1) Turn the power OFF.
2) Disconnect the JIG cable "#1," then turn the power ON.
M
KEY ASSIGNMENTS FOR THE ADJUSTMENT MODE
