Classic SE FF - Installation & Servicing
SHORT LIST OF PARTS
Key No. GC Part No. Description Qty. Product No.
9 E83-619 Sightglass assembly kit 1 171 414
12 Main burner
E72-529 SE9 FF & SE12 FF 1 171 012
E72-531 SE15 FF & SE18 FF 1 171 013
E85-891 SE21 FF, SE24 FF & SE30 FF 1 171 416
13 Main burner injector
E85-308 SE9 FF 1 171 424
E83-624 SE12 FF 1 171 425
E83-625 SE15 FF 1 171 426
E83-626 SE18 FF 1 171 427
E87-010 SE21 FF 1 171 428
E87-013 SE24 FF 1 171 429
E87-016 SE30 FF 1 171 430
14 Pilot burner injector:
E83-627 SE9, 12, 15, 18, 21, 24 FF 1 171 434
E80-493 SE30 FF 1 171 435
15 Pilot burner head Q359A with:
E83-630 injector SE9, 12, 15, 18, 21, 24 FF 1 171 438
E87-018 injector SE30 FF 1 171 439
17 E83-633 Gas valve kit 1 171 441
18 E83-635 Ignition electrode complete with lead and backnut 410 mm lg. 1 171 442
19 Control box assembly, including PCB 1 171 894
23 H20-882 PCB25E 1 173 799
24 E83-653 Pressure switch: 1 171 454
30 Fan assembly:
E83-665 SE9, 12, 15, 18, 21, 24 FF 1 171 461
E87-032 SE30 FF 1 171 462
35 Boiler casing assembly complete
H08-992 SE9, 12, 15, 18, 21, 24 FF (white) 1 173 582
H08-993 SE9, 12, 15, 18, 21, 24 FF (silver) 1 173 583
H08-995 SE30 FF (white) 1 173 584
H08-997 SE30 FF (silver) 1 173 585
37 H08-998 Controls casing door complete (white) 1 173 586
H08-999 (silver) 1 173 587
39 E85-313 Casing seal kit (white) 1 171 479
H08-736 (silver) 1 173 588
45 E83-682 Overheat thermostat 1 171 950
59 E97-310 Limit thermostat 1 173 353
The following are parts commonly required due to damage or expendability.
Their failure or absence is likely to affect safety or performance of this appliance.
The list is extracted from the British Gas List of Parts, which contains all
available spare parts.
The full list is held by British Gas, Ideal Stelrad Group distributors and
merchants.
When ordering spares please quote:
1. Boiler Model
2. Appliance G.C. Number
3. Description
4. Quantity
5. Product Number
When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Boilers.
