IDS 816 User Manual

IDS816 User Manual 700-283-01H Issued January 2009
16
Example:
To add a new user code, enter the User Program Mode by completing steps 1 to 5 as listed above.
To access Option 0, enter a value of [0] (See table 1) followed by [*].
Enter a [NEW USER CODE] followed by the [*] key. Once the user code is programmed, enter the next
code followed by [*]. To exit the program mode press the [#] key. For a full list of options, refer to Table
1. Programming of these options is explained on the previous page.
13.
13. 13.
13. Explanation of Pro
Explanation of ProExplanation of Pro
Explanation of Programmable Options
grammable Optionsgrammable Options
grammable Options
13.1
13.1 13.1
13.1 Add a New
Add a New Add a New
Add a New User
UserUser
User C
C C
Code
ode ode
ode –
––
– Option 0
Option 0 Option 0
Option 0
Hold down the [*] key until the beep,
then enter [MASTER CODE] [*] [0] [*] [New USER CODE] [*]
1. Enter the User Program Mode as per steps 1 to 4 on page 14.
2. Press the [0] key followed by the [*] key to select the programmable option 0 (zero). The Ready
and Armed indicators will flash simultaneously.
3. Enter the [New USER CODE] followed by the [*] key.
4. Further codes may be added by repeating step 3 above.
5. After entering the last code, press the [#] key to exit the user program mode.
13.2
13.2 13.2
13.2 Edit a User Name
Edit a User Name Edit a User Name
Edit a User Name –
––
– Option 1 (LCD Keypads O
Option 1 (LCD Keypads O Option 1 (LCD Keypads O
Option 1 (LCD Keypads Only)
nly)nly)
nly)
Hold down the [*] key until the beep,
then enter [MASTER CODE] [*] [1] [*] [User Name] [*]
1. Enter the User Program Mode as per steps 1 to 4 on page 14.
2. Press the [1] key followed by the [*] key to select programmable option 1. The Armed indicator
will flash.
3. Enter the [USER CODE] of the user whose name you wish to edit.
4. User Names are displayed as the User Slot Number by default. Edit the User Number so that it
reads the correct User Name. To confirm the entry press [*].
5. The [P] key can be used to move the cursor towards the right, whilst the [F] key can be used to
move from the curser towards the left. The [MODE] key toggles between upper and lower case
(underscore curser for lower case, block curser for capitals).
6. Repeat steps 3 to 5 until you have edited all the names you require and then press [#] to exit.
13.3
13.3 13.3
13.3 Edit a Selected
Edit a Selected Edit a Selected
Edit a Selected User
UserUser
User C
C C
Code
odeode
ode –
––
– Option 2
Option 2 Option 2
Option 2
Hold down the [*] key until the beep,
then enter [MASTER CODE] [*] [2] [*] [Old Code] [*] [New Code] [*]
1. Enter the User Program Mode as per steps 1 to 4 on page 14.
2. Press the [2] key followed by the [*] key to select programmable option 2. The READY and Armed
indicators will flash simultaneously.
3. Enter the [USER CODE] which is to be edited followed by the [*] key.
4. The READY indicator will flash and the AWAY indicator will be on.
