IDS 816 User Manual

IDS816 User Manual 700-283-01H Issued January 2009
23
Table 3 Trouble Conditions
Indicator
IndicatorIndicator
Indicator Trouble Condition
Trouble ConditionTrouble Condition
Trouble Condition
1 AC mains failure
2 Failure to communicate successfully to monitoring company
3 Phone line trouble
4 Siren tamper
5 Low battery
6 Loss of clock timer
7 Engineer reset
8 Box tamper
9 n/a
10 Tamper on peripheral device
11 Communication loss to peripheral device
12 Loss of power to peripheral devices
13 Reserved
18.
18. 18.
18. Chang
ChangChang
Changing a Partition
ing a Partitioning a Partition
ing a Partition
Hold down the [MODE] key until the beep,
then enter [1] [*] [PARTITION NUMBER] [*]
To change partitions the keypad must be a global keypad.
1. Ensure that the Panel is disarmed
2. Hold [MODE] until the keypad beeps.
3. Press [1] [*] followed by the [PARTITION NUMBER] [*].
If no key is pressed on the keypad for specified delay period (default is 20 seconds), the keypad will
beep and default back to its original partition. The keypads may be programmed to remain in the new
partition. (Ask your Installer about this option). Entering partition numbers other than 1 or 2 will produce a
key entry error.
19.
19. 19.
19. Output Control via a Keypa
Output Control via a KeypaOutput Control via a Keypa
Output Control via a Keypad
dd
d
If the panel has been set up to control switching functions via its outputs, these can be controlled via the
keypad - e.g. turning lights on and off.
Hold down the [MODE] key and press [3] [*].
(Any outputs that are currently set [ON] will be shown as an on zone indicator.)
To toggle the output status, enter [OUTPUT NUMBER] followed by [*]. Press [#] to exit User Program
Mode.
Ensure that you have checked with your installer which outputs are used for radio reporting to
prevent the triggering of false alarms.
