IDS 816 User Manual

IDS816 User Manual 700-283-01H Issued January 2009
22
16.
16. 16.
16. Chime Zones
Chime ZonesChime Zones
Chime Zones
The chime mode allows the user to monitor nominated zones while the system is disarmed. The keypad
buzzer will sound five times when the nominated zone is violated - the siren will NOT sound and no alarm
condition will be reported.
EXAMPLE:
EXAMPLE: EXAMPLE:
EXAMPLE:
If you wish to know each time someone enters or exits the front door of your office, program this zone as
a chime zone. The keypad will beep each time someone opens the front door.
16.1
16.1 16.1
16.1 How to Program Chime Zones
How to Program Chime ZonesHow to Program Chime Zones
How to Program Chime Zones
Hold down the [2] key until the beep,
then enter [ZONE NUMBER] [*] [#]
1. Select the required stay profile (See Page 19)
2. Hold down the [2] key until the keypad buzzer sounds. The AWAY indicator will flash indicating
that the panel is in the Chime zone programming mode.
3. Entering a zone number will toggle the corresponding LED. For example, [2] [*] will turn LED 2 on
(if it was off) and off (if it was on).
4. Turn on the LED’s corresponding to the zones you need to be CHIME zones. The LED zone
indicators should now indicate only the zones that you require to be CHIME zones.
5. Once satisfied with your selection, press the [#] key to exit the CHIME zone mode.
17.
17. 17.
17. Viewing Trouble Conditions
Viewing Trouble ConditionsViewing Trouble Conditions
Viewing Trouble Conditions
Hold down the [7] key until the beep
The user is alerted to a trouble condition via a flashing power LED. It is also possible to enable a trouble
beep. (Ask your Alarm Panel Installer)
If the trouble beep has been enabled, the keypad buzzer will sound to alert the user that a
trouble condition has occurred. Press the [#] key to silence the buzzer.
Hold down the [7] key for two seconds. The ARMED, AWAY and READY indicators will be
flashing simultaneously showing that the keypad is in the TROUBLE VIEW MODE. Refer to Table 3 to find
the significance of each on zone LED. The system will automatically exit the TROUBLE VIEWING MODE
after one minute. (Alternately to exit this mode press [#].)
NOTE:
Certain trouble conditions will only clear once the trouble condition has restored. To cancel the beeping
without viewing the trouble conditions, press [#] key.
