IKONIX apt 400XAC Series User Manual

142
Part Number
Qty.
Ref.
Designator
Description
39444
1
-
Right Side Panel
39220
1
EVR1
Rotary Encoder
38973
1
-
Rotary Knob
38274
12
-
Button Keypad Rect. 9.8 x 8.0mm
38275
6
-
Button Keypad Rect. 9.8 x 4.9mm
39664
2
-
Front Wheel with brake 3.5” H
39665
2
-
Rear Wheel 3.5” H
38916
1
-
Graphic LCD Display
39452
2
-
Diode LED Red Round
38759
1
-
Output Terminal Block 30A, 5
positions (430XAC)
39458
1
-
Sense Terminal Block 20A, 4
positions
39170
1
-
Input Terminal Block 30A, 3
positions
39171
1
-
Input Terminal Block 30A, 4
positions. (460XAC)
39463
1
-
Output Terminal Block 75A, 5
positions. (460XAC)
PCB Assemblies
38967
1
KEY6700
Keypad Board
39063
1
USB/RS232
USB/RS232 Interface Board
38305
1
CGP-03
GPIB Interface Board
38819
1
38818
Ethernet Card
39405
1
CONM001
Main Control Board
39437
1
ANGAC300
Analog Board
39121
3
AMP61000
Amplifier Board (430XAC)
39122
3
AMP61000
Amplifier Board (460XAC)
39123
1
DDC61000
DC to DC Converter Board
(430XAC)
39124
3
DDC61000
DC to DC Converter Board
(460XAC)
39127
1
PFC61000
PF Correct Board (430XAC)
39466
3
PFC61000
PF Correct Board (460XAC)
39130
1
FLY61000
FLY Back Board
