Immergas VICTRIX 50 User Manual

38
STV50 ed 09/08 VICTRIX 50 Rev. 002
VICTRIX 50 combustion parameters.
NATURAL GAS (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
BURNER GAS
FLOW RATE
FAN SPEED (RPM)
BURNER GAS
FLOW RATE
FAN SPEED (RPM)
BURNER GAS
FLOW RATE
FAN SPEED (RPM)
(kW) (kcal/h) (m
3
/h) (n°) (kg/h) (n°) (kg/h) (n°)
50,0 43000 5,37 5180 4,01 4600 3,94 5200
48,0 41280 5,16 5000 3,85 4430 3,79 5000
46,0 39560 4,95 4810 3,70 4260 3,64 4790
44,0 37840 4,74 4620 3,54 4090 3,48 4590
42,0 36120 4,53 4430 3,38 3910 3,33 4380
41,2 35398 4,45 4350 3,32 3840 3,26 4300
38,0 32680 4,11 4050 3,07 3570 3,02 3980
36,0 30960 3,90 3860 2,91 3390 2,86 3780
34,0 29240 3,69 3670 2,75 3220 2,71 3580
32,0 27520 3,48 3470 2,59 3050 2,55 3380
30,0 25800 3,26 3280 2,44 2880 2,40 3180
28,0 24080 3,05 3080 2,28 2700 2,24 2980
26,0 22360 2,84 2890 2,12 2530 2,08 2790
24,0 20640 2,62 2690 1,96 2360 1,92 2590
22,0 18920 2,41 2490 1,80 2190 1,77 2400
20,0 17200 2,19 2290 1,63 2010 1,61 2200
18,0 15480 1,97 2090 1,47 1840 1,45 2010
16,0 13760 1,76 1890 1,31 1670 1,29 1820
14,0 12040 1,54 1690 1,15 1500 1,13 1630
12,0 10320 1,32 1490 0,99 1330 0,97 1440
10,0 8600 1,10 1280 0,82 1150 0,81 1250
VICTRIX 50 variable heat output.
G20 G30 G31
Gas nozzle diameter mm 7,85 5,70 5,70
Supply pressure mbar (mm H
2
O) 20 (204) 29 (296) 37 (377)
Flue ow rate at nominal heat output kg/h 81 72 81
Flue ow rate at minimum heat output kg/h 17 15 17
CO
2
at Q. Nom./Min. % 9,32 / 9,25 12,30 / 11,70 10,60 / 10,10
CO at 0% of O
2
at Q. Nom./Min. ppm 130 / 5 425 / 10 120 / 7
NO
X
at 0% of O
2
at Q. Nom./Min. ppm 69 / 28 342 / 85 119 / 43
Flue temperature at nominal heat output °C 41 46 42
Flue temperature at minimum heat output °C 47 51 47
