STVZ ed 02/06 VICTRIX Zeus
Technical Documentation
Technical Documentation
VICTRIX ZEUS
Condensation-type wall-hung room sealed
fan-assisted boiler with Gaudium Ma-
gnum device.
VICTRIX Zeus 20
VICTRIX Zeus 27
General features.
VICTRIX Zeus is a condensation-type wall-hung room sea-
led fan-assisted boiler featuring a “Gaudium Magnum” devi-
ce for fully exploiting the characteristics of this 54 l boiler in
Aisi 316L stainless steel.
ere are two versions in the range with working outputs of
23.5 kW (20210 kcal/h) and 31.4 kW (27000 kcal/h) and
both feature an innovative total premix combustion system
that ensures very low pollutant emissions and enables the boi-
ler to run on natural gas and LPG.
e high energy output has been awarded the 4-star mark
(´´´´) in conformity with P.D. 660/96.
e appliance is regulated and controlled by means of a prin-
ted microprocessor control board which, through a monitor,
displays the state of boiler operation (temperature, safety devi-
ces, etc.) and enables it to be connected (optional) to the Ami-
co Remote Control, to the area unit and to the Multisystem
Water Disconnector.
e hydraulic circuit features a coil water-gas exchanger in
STAINLESS steel, a 3-way electric valve and a 2 l d.h.w.
expansion vessel.
VICTRIX Zeus must be installed using the aspiration/drai-
nage kit or the piping system (Ø 60 mm rigid and Ø 80 mm
flexible) made of plastic material and expressly conceived for
Immergas condensation boilers.
