- 23 -
Installation and Wiring
NOTE
◆ S1: RS-485 communication protocol termination resistor selection.
Left: The bus termination resistor available
Right: The bus termination resistor not available
◆ J2: Temperature detection selection.
Left: PTC
Right: PT100
◆ J3：DI reference point selection.
Left: 24V
Right: CGND
