Inovance Aonarch MD500L Series User Manual

- 55 -
Parameter Table
Group F2: vector control
Parameter Parameter Name Setting Range Unit Default Commission
F2-00
Speed loop proportional
gain 1
0 to 100 N.A 15 -
F2-01
Speed loop integral time
1
0.01 to 10.00 s 0.30 -
F2-02 Switchover frequency 1 0.00 to F2-05 Hz 3.00 -
F2-03
Speed loop proportional
gain 2
0 to 100 N.A 30 -
F2-04
Speed loop integral time
2
0.01 to 10.00 s 0.5 -
F2-05 Switchover frequency 2 F2-02 to max. output frequency Hz 7.00 -
F2-06 SVC slip gain 50 to 200 % 100 -
F2-10
Torque upper limit (for
SVC)
0.0 to 200.0 (% AC drive rated
current)
% 150.0 -
F2-13
Excitation adjustment
proportional gain
0 to 20000 N.A 2000 -
F2-14
Excitation adjustment
integral gain
0 to 20000 N.A 1300 -
F2-15
Torque adjustment
proportional gain
0 to 20000 N.A 2000 -
F2-16
Torque adjustment
integral gain
0 to 20000 N.A 1300 -
F2-20 Retard coe󶎀cient 0 to 200 N.A 50 -
Group F3: V/F control
Parameter Parameter Name Setting Range Unit Default Commission
F3-00 V/F curve setting
0: Linear V/F
1: Multi-point V/F
2 to 11: no relevant settings
N.A 0 -
F3-01 Torque boost
0.0 to 30.0 (if it is 0, then auto
torque boost is activated)
% 0 -
F3-02
Cut-o󶍽 frequency of
torque boost
0.00 to max. output frequency Hz 50.00 -
F3-03
Multi-point V/F
frequency 1 (F1)
0.00 to F3-05 Hz 1.50 -
F3-04
Multi-point V/F voltage 1
(V1)
0.0 to 100.0 % 6.0 -
