- 38 -
Quick setup
Set DC injection for
stopping
F6-11 DC injection 2 frequency threshold 0.50 0.50
0.00 Hz to maximum frequency
F6-12 DC Injection 2 delay ON set time 0.0 0.0
0.0 to 36.0s
F6-13 DC injection 2 level 30 30
0 to 100 Hz
F6-14 DC injection 2 active set time 0.5 0.5
0.0 to 36.0s
Set V/F parameters
F3-00 V/F curve selection 0 0
0: Linear V/F
1: Multi-point V/F
Setting range: 0 to 11
F3-01 Torque boost 0.0 0.0
0.0 to 30.0 %;
NOTE: If it is 0, then auto torque boost is activated, and it is recommended
to use auto torque boost.
Set SVC parameters
F2-00 Speed loop proportional gain 1 10 10
0 to 100
F2-01 Speed loop integral time 1 0.5 0.5
0.01 to 10.00s
F2-02 Switchover frequency 1 3.00 3.00
0.00 Hz to F2-05
F2-03 Speed loop proportional gain 2 30 30
0 to 100
F2-04 Speed loop integral time 2 0.5 0.5
0.01 to 10.00s
F2-05 Switchover frequency 2 7.00 7.00
F2-02 to maximum output frequency
OVER
To Next Page
