Inovance Aonarch MD500L Series User Manual

- 58 -
Parameter Table
Parameter Parameter Name Setting Range Unit Default Commission
F4-08
PTC function enable
(On-board expansion
card)
37: Command source switchover
terminal 2
38: PID integral pause
39: Switchover between main
frequency source X and
preset frequency
40: Switchover between auxiliary
frequency source Y and
preset frequency
41: Motor selection terminal 1
42: Motor selection terminal 2
43: PID parameter switchover
44: User de󶍾ned fault 1
45: User de󶍾ned fault 2
46: Speed control/Torque control
switchover
47: Emergency stop
48: External STOP terminal 2
49: Deceleration DC braking
50: Clear the current running
time
51: Switchover between two-line
mode and three-line mode
52 to 59: Reserved
-
F4-10 DI 󶍾lter time 0.000 to 1.000 s 0.010 -
F4-11
Terminal command
mode
0: Two-line mode 1
1: Two-line mode 2
2: Three-line mode 1
3: Three-line mode 2
N.A 0 -
F4-12 Terminal UP/DOWN rate 0.01 to 65.535
Hz/
s
1.00 -
F4-13
AI curve 1 minimum
input
0.00 to F4-15 V 0.00 -
F4-14
Corresponding setting
of AI curve 1 minimum
input
-100.00 to 100.00 % 0.0 -
F4-15
AI curve 1 maximum
input
F4-13 to 10.00V V 5.00 -
F4-16
Corresponding setting
of AI curve 1 maximum
input
-100.00 to 100.00 % 100.0 -
F4-17 AI1 󶍾lter time 0.00 to 10.00 s 0.10 -
