Parameter Table
Parameter Parameter Name Setting Range Unit Default Commission
F5-02
Relay function (T/A-T/BT/
C)
9: Designated count value
reached
10: Length reached
11: PLC cycle complete
12: Accumulated running time
reached
13: Frequency limited
14: Torque limited
15: Ready for RUN
16: AI1 larger than AI2
17: Frequency upper limit
reached
18: Frequency lower limit reached
(no output at stop)
19: Undervoltage state output
20: Communication setting
21-22: Reserved
23: Zero-speed running 2 (having
output at stop)
24: Cumulative power-on time
reached
25: Frequency-level detection
FDT2 output
26: Frequency 1 reached
27: Frequency 2 reached
28: Current 1 reached
29: Current 2 reached
30: Timing reached
31: AI1 input limit exceeded
32: Load becoming 0
33: Reverse running
34: Zero current state
35: Module temperature reached
36: Software current limit
exceeded
37: Frequency lower limit reached
(having output at stop)
38: Alarm output
39: Motor overheat warning
40: Current running time reached
41: Fault output (There is no
output if it is the coast-to-
stop fault and if undervoltage
occurs.)
42: Brake output
43: MC (Magnetic contactor)
output
44: Rescue Operation output
N.A 43 -
F5-03
Extension card relay
function (BK+/BK-)
N.A 42 -
F5-04
DO1 function selection
(open-collector output
terminal)
N.A 0 -
F5-05
Extension card relay
function (MC+/MC-)
N.A 0 -
