‑9‑
No. Name
Description
4
Color
identification
Red: Digital output Orange: Analog output
Gray: Digital input Green: Analog input
White:
Communication
Blue: Other module
1.3 Specifications
■ Power supply specifications
Item Specification
Rated bus input voltage 5 VDC (4.75 VDC to 5.25 VDC)
Rated bus input current 100 mA (typical@5 V)
Rated terminal input voltage 24 VDC (20.4 VDC to 28.8 VDC)
Rated terminal input current 12 mA (typical@24 V)
Rated terminal output voltage N/A
Rated terminal output current N/A
Hot swap Not supported
■ Output specifications
Item Specification
Output type Digital output, NPN
Output mode Sinking
Output channels 16
Output voltage class 24 VDC±10% (21.6 VDC to 26.4 VDC)
Output load (resistive
load)
0.5 A/ point, 4 A/ module
Output load (inductive
load)
7.2 W/ point, 24 W/ module
Output load (lamp load) 5 W/ point, 18 W/ module
ON/OFF response time 100 us/100 us
Leakage current at OFF 10 uA
