‑10‑
Item Specification
Switching frequency 100 Hz with resistive load, 0.5 Hz with inductive load, 10 Hz with
lamp load
Isolation Yes
Output action display Output indicators are turned ON (via software control) when the
outputs are in the driving state
Output derating 50% derating at 55°C (the output current does not exceed 2A
when all outputs are ON ), or 10°C derating when all outputs are
ON
Protection function Short circuit protection, overcurrent protection
■ Software specifications
Item Specification
Output mode upon stop Output zero, output last value, output preset
value
Preset value 0 or 1
Output port anomaly detection and
indication
N/A
Output channel logic level
configuration
Not supported
Independent channel enable
configuration
Not supported
Diagnostic report configuration Not supported
When in stop mode Output according to output mode upon stop and
present value, no refresh
I/O mapping Supports bitwise, bytewise and wordwise
addressing
