12
NS-32D220NA18/NS-32D220MX18/NS-43D420NA18
www.insigniaproducts.com
3 Attach the wall-mount bracket to your TV using the mounting holes on the back of your TV. See the instructions that
came with the wall-mount bracket for information about which screws to use and how to correctly hang your TV.
Notes
• The length of the wall-mount screws vary depending on the wall-mount
bracket you purchased. See the instructions that came with the
wall-mount bracket for screw lengths.
• The mounting holes on the back of the 32" model take type M4 screws.
The mounting holes on the back of the 43" model take type M6 screws.
32": 3.9 in. (100 mm)
43": 7.9 in. (200 mm)
32": 3.9 in. (100 mm)
43": 7.9 in. (200 mm)
