Technical Reference
81
Midboard Connectors
Audio Connectors
Figure 29 shows the location of the audio connectors.
OM11638
CA
B
1
4
1
10
9
2
1
4
Item Description
A ATAPI-style auxiliary line in
B Front panel audio (optional)
C ATAPI-style CD-ROM
Figure 29. Audio Connectors (the D815EEA2 Board Is Shown)
