Utilities and Applications 5-5
HARDWARE
This function attempts to determine if a PCMCIA controller exists on the
machine. It first checks for PCI BIOS extensions, and then it searches for
any PCMCIA controllers. If found it displays controller type, base I/O
address, offset, number of the socket in which the PRO/100 is installed,
and the PCI interrupt (if enabled by the BIOS).
NETWORK
This function enables the card on the Ethernet network and performs
some diagnostics. It reports the operating mode and speed detected and
monitors the network for traffic. Network traffic is shown on a graph.
This graph provides a visual representation of the volume of traffic on the
local area network (LAN). The Receive Statistics window displays the
cumulative totals for received Packets, KBytes, and Errors.
RESOURCES
This function attempts to determine free resources that are available for
use by the driver. It searches for memory, I/O, and IRQ.
ADVANCED
This function allows the user to set up advanced diagnostics.
ABOUT
This function displays the current version of the diagnostic program.
HELP
This function displays the help screen.
EXIT
This function exits the application.
COM port monitor (Windows 3.x only)
The Intel COM Port Monitor is an onscreen LED program that runs
under Microsoft Windows 3.1 and 3.11, and Windows for Workgroups
3.11. The program provides a simulated onscreen display of modem status
LEDs such as those found on external modems.
