A SQUALL II MODULE INTERFACE
5-17
5.7 Squall II Module Connector
The Squall II Module interface uses a 100-pin surface mount connector plug. Samtec* part number for
the connector is TFM-150-32-SDLC. Table 5-6 shows pin assignments for the Squall II Module
connector.
Table 5-6. Squall II Module Pin Assignments
Pin Signal Pin Signal Pin Signal Pin Signal Pin Signal
1 S_ADS 21 S_EXTEND
41 GND 61 S_A22 81 S_A03
2 GND 22 GND 42 S_D15 62 S_A21 82 S_A02
3 PMCLK 23 +5V 43 S_D14 63 S_A20 83 +5V
4 GND 24 S_D31 44 S_D13 64 S_A19 84 S_D07
5 S_BLAST
25 S_D30 45 S_D12 65 S_A18 85 S_D06
6 S_LOCK
26 S_D29 46 S_D11 66 S_A17 86 S_D05
7 S_W/R
27 S_D28 47 S_D10 67 S_A16 87 S_D04
8 GND 28 S_D27 48 S_D09 68 +5V 88 S_D03
9 S_READY
29 S_D26 49 S_D08 69 S_A15 89 S_D02
10 RESET
30 S_D25 50 GND 70 S_A14 90 S_D01
11 S_BE0
31 S_D24 51 S_A31 71 S_A13 91 S_D00
12 S_BE1
32 GND 52 S_A30 72 S_A12 92 GND
13 S_BE2
33 S_D23 53 S_A29 73 S_A11 93 +5V
14 S_BE3
34 S_D22 54 S_A28 74 S_A10 94 ---
15 SQSEL
35 D_D21 55 S_A27 75 S_A09 95 ---
16 GND 36 S_D20 56 S_A26 76 S_A08 96 GND
17 SQIRQ1
37 S_D19 57 S_A25 77 S_107 97 SQSDA
18 SQIRQ0
38 D_D18 58 S_A24 78 S_A06 98 SQSCL
19 SQBR
39 S_D17 59 +5V 79 S_A05 99 +12V
20 SQBG
40 D_D16 60 S_A23 80 S_A04 100 ---
