4 Intel
®
Server Board S5500BC User’s Guide
H. Slot 5, PCI Express* x8 S. DIMM sockets off
Processor 1 socket
(Channel A, B)
DD. DIMM sockets off
Processor 2
socket (Channel
D, E)
I. Slot 6, PCI Express* x8
(Riser card)
T. Power Supply
Auxiliary Connector
EE. SATA SGPIO
J. Slot 7, PCI Express* x8 U. SSI 24-pin Front
Panel connector
FF. SATA 0
K. Back panel I/O ports V. System fan 2 header GG. SATA 1
