8.6.6 Status bar
The status bar shows the status of the ABR test:
• Ready (before testing)
• Running (during testing)
• Pass (when is test completed)
• Refer (when test is completed)
8.6.7 ABRIS response curve
The response curve indicates the test status over time. When the response curve reaches the 100% line
before the test runs out (120 sec), a pass indication is displayed in the status bar above the curve. If the
100% detection line is not reached during the 120 seconds, a Refer is displayed.
