Interlogix Caddx User Manual

LED Keypad

5 ZONE TROUBLE -
Press [
5
] and the
zone light(s)
will illuminate showing
which zone(s) has a trouble condition. Press [
#
] key to return to the 1 of 8
service lights
.
TELEPHONE LINE TROUBLE/LINE CUT
– Press [
6
]. The zone light(s) will
illuminate as they correspond to these service conditions:
1-5 = Reserved 6 = Telephone Line Trouble / Line Cut
7 = Aux communication device failure
6
The
service light
will remain lit until the trouble clears and a user code is
entered.
* SEE NOTE.
7 FAILURE TO COMMUNICATE –
Illuminated when there is a failure to
communicate between your system and the central station.
* SEE NOTE.
8 LOSS OF SYSTEM TIME
- Illuminated when there has been a loss of power
and your system clock needs to be reset. Instructions are on page 12.
*
SEE NOTE.
TO EXIT THE SERVICE LIGHT MODE, PRESS [#]
* NOTE to Lights 6,7,8: This fault is global in nature and will affect all partitions of a
multi-partition system.
KEYPAD CONTROL TONES (BEEPS)
A sounder is built into the keypad. If programmed, your system keypad may sound for
any of the following reasons:
•
Beeps for all keypresses.
•
Sounds a continuous tone during the Entry delay time.
•
Pulses when a day zone is violated while the system is disarmed.
•
Pulses when a FIRE zone has a trouble condition.
•
Beeps 3 times for trying to arm with the “Ready” light off, if “Force Arming” has
not been selected.
•
Beeps for 1 second or emits a “ding-dong” sound for the “Chime” feature.
•
Beeps during an exit delay; beeps rapidly for the last 10 seconds of an exit
delay; and beeps 1 second at the end of the exit delay.
•
Pulses when the armed status changes and the AC power is off.
•
Pulses when the armed status changes and any zone(s) are bypassed.
•
Pulses when the armed status changes and a low battery is detected.
•
Pulses when the armed status changes and a Tamper condition is detected.
•
Beeps to indicate Telephone Line Cut, if selected.
•
Pulses when one or more of the following conditions are detected: Zone or Box
Tamper, Low Battery, AC Power Fail, or Expander trouble.
•
Beeps 3 times every minute indicating a low battery or missing transmitter is
detected (if wireless device is in system). Entering code will suppress the
sounder for 12 hours.
Entering a valid code will silence the keypad sounder when it is pulsing. The
arm/disarm state of your system will not change when entering a code to silence a
pulsing keypad sounder. Please contact your installer if a trouble condition exists.
