Invacare Leo Service Manual

SERVICE MANUAL
Invacare
®
- Leo
14
4 Service plan (1x annually)
Component Check Remedy Notes
ü
Seat:
• Welded seams,
fixings and
upholstery
• Tighten screws,
replace parts if
damaged
• Seat suspension
• Grease the spring
generously,
replace parts if
damaged
See "Replacing the
seat suspension /
spring" on page 34
Frames
(chassis) /
battery
mounting
• Check fixings,
welded seams and
battery mounting
• Check battery fixing
straps
• Tighten screws,
replace parts if
damaged
Wheel
suspension and
wheels
• Check drive wheels
for tight fit
• Tighten hub nuts,
replace if
necessary
• Check steering
wheels for tight fit,
float and side play
• Adjust / replace
See "Assembling
and
disassembling the
wheels (4-wheel
version and rear
wheels on the 3-
wheel version)"
on page 21
• Pneumatic tyre
• Repair or replace
if damaged
See operating
manual
• Check tracking and
steering linkage.
• Tighten screws
• Check tracking
and steering
Drive units,
coupling
mechanism
• Check functions in
drive and push
modes
• Check clutch
mechanism
• Replace motor if
necessary
• Tighten screws /
nuts, adjust or
replace
See "Replacing
the drive motor"
on page 21
Batteries
• Check batteries for
damage
• Replace batteries
See operating
manual
• Check battery
voltage
• charge batteries
See operating
manual
• Check contacts and
terminals
• Clean contacts
and terminals
Drive
electronics
• Status display
flashing
• Fixing
• Cable, connecting
plug
• Drive lever function
• Power supply
• Evaluate blinking
code
• Tighten or replace
fixing.
• Replace cable,
connecting plug.
• Replace drive
lever
• Replace cable,
connecting plug or
console
