6 Repair Work
6.1 General warning information on installation work
CAUTION!
Risk of damage to the vehicle! Collisions can be caused if shim rings are removed from
the drive wheels during installation work!
Shim rings are frequently placed between the drive shaft and the wheel hub to compensate
tolerances. Collisions can be caused if these shim rings are removed and not re-installed!
• Install all shim rings in exactly the same positions they were in before dismantling.
6.2 Assembling and disassembling the front
wheel/axle (3-wheel version)
CAUTION: Danger of accidents!
Accidents may result from standing the chassis upright on its end!
• Secure the chassis against falling over!
WARNING!
Danger of damage to the scooter! The plastic cover can be damaged if you attempt to lift
the vehicle by its cover!
• Only lift the vehicle by the chassis.
Note
Pay attention to the positions of small parts such as screws and washers during disassembly. Put
small parts aside in such a way that they can be re-fitted in the correct order.
Requirements:
• 12 mm spanner
• 13 mm spanner
• Self-locking nut 13 mm
• Remove the seat.
• Remove the batteries.
• Remove the drive unit.
