SECTION 11—TRANSPORTING
Part No. 1125053 45 Zoom
220
SECTION 11—TRANSPORTING
WARNING
After ANY adjustments, repair or service and BEFORE use, make sure that all
attaching hardware is tightened securely - otherwise injury or damage may result.
Before performing any maintenance, adjustment or service, turn power off and
remove key from ignition.
DO NOT lift the scooter by the rear shroud - otherwise damage to the scooter may
occur.
Transporting the Scooter
NOTE: For this procedure, refer to FIGURE 11.1.
Disassembling
1. Turn power off and remove the key from the ignition.
2. Ensure that the brake release lever is engaged. Refer to Engaging/Disengaging the
Brake Release Lever on page 27.
3. Remove the seat. Refer to Removing/Installing the Deluxe Seat on page 31 or
Removing/Installing/Adjusting the Padded Seat on page 29.
4. Remove the battery box. Refer to Removing/Installing the Battery Box on page 41.
5. Flip up the frame lock pin located on under the flap on the floor mat (not shown).
6. Hold the frame post in one hand and the tiller in the other hand and pull apart the rear
and front frame assemblies.
7. Fold tiller down to lowest locked position. Refer to Adjusting the Tiller Angle
on
page 35.
Assembling
WARNING
BEFORE use, ensure that the frame lock pin is in the LOCKED (horizontal) position
securing the front and rear frame assemblies together. Otherwise injury and/or
damage may occur.
1. Unfold tiller. Refer to Adjusting the Tiller Angle
on page 35.
2. Flip up the frame lock pin.
3. Hold the tiller in one hand and the front frame assembly in the other hand and align
the front frame assembly with the alignment pins on the rear frame assembly.
