Advanced Function
Batt Mode Battery test mode, charging mode and
discharging mode can be select.
Charge Battery charging mode
Discharge Battery discharging mode
Disch/Charge V Set the charging voltage or discharging
voltage. The displayed value is different
under charge mode and discharge mode.
Disch/Charge I Set the charging current or discharging
current. The displayed value is different
under charge mode and discharge mode.
Disch/Charge
Time
Set the charging or discharging time.
Cut Off V Set the cut off voltage.
Cut Off I Set the cut off current.
Cut Off Q Set the cut off capacity.
During editing, the instrument would automatically return to the main
interface if there is no operation for a long period.
operation steps:
1. Under source mode, press [Shift]+[I-set](Function) to enter into the function
menu interface.
2. Rotate the knob to select Battery, and press [Enter].
3. Rotate the knob to select Run, Recall, Edit in turn.
Run Recall Edit
4. Select different functions for setting, for detailed operation about battery file
editing, recalling and running, please refers to following introduction.
The running, recalling and editing of List function are mutual
prerequisites. When the system has no existed battery test file, it is
necessary to edit battery test file, recall battery test file, and finally run the
recalled battery test file.
Edit Battery Test File
1. In the battery test function setting interface, select the Edit and enter to the
edit file menu.
Copyright © Itech Electronic Co., Ltd.
56
