2. Set the voltage and frequency parameters in the sweep interface.
Parameters in the sweep interface are described as follows:
Parameter
Explain
Start voltage
Set the starting voltage.
Stop voltage
Set the ending voltage.
Step Voltage
Set the step voltage.
Start freq
Set the starting frequency.
Stop freq
Set the ending frequency.
Step freq
Set the step frequency.
Step time
Set the step time.
Mode
Set the sweep mode.
Time
: Time Sweep Mode
Trig: Trigger mode
Priority
Priority setup
V-
First
F-
First
VF
Waveform
Select sweep waveform
Sine
Square
Sawtooth
Triangle
Trapezoid
Finish
Set the running state after the sweep
execution is
finished:
• off: Directly off the output after the
execution is finished;
• Last: Keep the
last waveform unchanged
after the execution is finished.
Trig source
Select the Trigger source:
Manual
TRIG1
TRIG2
3. Press [On/Off] on the front panel and enable the output.
4. Press [Run] on the Sweep interface, Then the running status [Active] will
be displayed on LCD. Output parameters and measurement parameters are
displayed on the left side of the Sweep interface. You can also press the
[Meter] to observe the output parameters in the main interface.
5. After sweeping, [On/Off] on the front panel will be off, and [Idle] status will
be displayed on LCD. You can press [Stop] on the Sweep interface to stop
the Sweep function.
