ITech IT8700 Series User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 75
OTP
≒85℃
Specification
Short-circuit
Current（CC）
≒3.3/3A
≒22/20A
Voltage（CV）
0V
Resistance（CR）
≒240mΩ
Input impedance
1MΩ
dimension
82*183*573
weight
5KG
safety
CE
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is:
（ 1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08) ）
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current
*5 Minimum rise time: 10%-90% current rise time
Model
IT8733BP
Rated value
( 0～40 ℃)
Input voltage
0~500V
Input current
0~30A
Input power
500W
Min operation voltage
0.54V/3A
5.4V/30A
CV mode
Range
0~18V
0~500V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.025%FS)
±(0.05%+0.025%FS)
CC mode
Range
0~3A
0~30A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CR mode
*1
Range
0.2Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
*3
Range
500W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Dynamic mode
Dynamic mode
CC mode
T1＆T2
20uS~3600S/Res:1uS
Accuracy
5uS±100ppm
Rising/falling slope
*4
0.0001~0.08A/uS
0.001~0.8A/uS
Min Rising time
*5
≒25uS
≒25uS
Measuring range
Readback voltage
Range
0~18V
0~500V
Resolution
1 mV
10 mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback current
Range
0~3A
0~30A
Resolution
0. 01mA
0.1mA
Accuracy
±(0.05%+0.05%FS)
Readback power
Range
500W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
