11 LIST OF COMPONENTS IN ILLUSTRATIONS
Figure
Item
Description
1
1
Top cover
2
Loaf pusher
3
Rear table
4
Blades
5
Front cover
6
Delivery table
7
Front bumper
8
Crumb tray
9
Bagger
10
Counter
11
Oil counter reset
12
Oil level indicator (Misch)
13
Castor
2
14
Rear panel
15
Electrical enclosure panel
16
Power cable
3
17
Work area
6
18
JAC Stop slice holding system
7
19
Front cover lock
10
20
“Cut hazard” sign
21
“Electrocution hazard” sign
22
Circuit diagram
