en-48
5 CONTROLS
5.12 STEERING TILT CONTROL ______________________________________________
When the operators seat is in the correct position to operate the Traction
Pedal comfortably, push the small Foot Pedal (A) at the base of the steer-
ing column, and tilt the column backward or forward to the correct posi-
tion. Release the small Foot Pedal to lock the steering column
in position.
5.13 HORN _______________________________________________________________
For machines without the lighting kit.
The horn button is situated on the control panel. If the lighting kit is fitted
the horn is located on the end of the indicator stalk.
5.14 POWER OUTLET ______________________________________________________
The auxiliary power outlet is located on the side of the control panel. It is
for use with mobile phone chargers and accessories.
Automotive 12 Volt, 10 Amp power outlet.
